Key Features & Benefits
-
- Heavy-Duty Hybrid Construction: Forged from corrosion-resistant aluminum alloy and industrial brass. Built to withstand high pump pressures and harsh open-field weather elements for long-term operational life.
- Massive Coverage Area: Tosses a powerful, sweeping water throw up to a 29-meter spray radius (58-meter total wetting diameter) to minimize the need for shifting hardware around your field.
- Interchangeable Nozzle System: Comes ready with 10mm, 12mm, 14mm, and 16mm nozzles. Swap them instantly to match specific crop growth stages, changing soil structures, or seasonal watering requirements.
- Flexible 1.5-Inch Connection: Features a standard 1-1/2″ Female BSP threaded base, allowing fast, leak-free assembly onto rising pipes or standard field tripod stands.
- Smooth Impact Rotation: Optimized drive-arm mechanics ensure a steady, slow-speed rotation. This eliminates uneven dry patches and prevents harmful localized waterlogging.
Technical Specifications
| Feature | Specification |
|---|---|
| Material | High-Grade Aluminum Alloy + Solid Brass |
| Inlet Connection Size | 1-1/2″ (1.5 Inch) Female BSP |
| Working Pressure (W.P.) | 2.0 – 5.0 bar |
| Included Nozzle Orifices | 10mm, 12mm, 14mm, 16mm |
| Maximum Spray Radius | Up to 29 meters |
| Carton Quantity | 10 pcs per box |
Best Used For
- Broad-acre crops like maize, wheat, sugarcane, and alfalfa.
- Pastures and livestock grazing fields requiring deep root saturation.
- Dust suppression and turf conditioning on farm roads and storage areas
